27kw Heating Tube Cooking Oil Purifier Machine , Soybean Oil Filter
Machine 1.1kw Pump
Applications of cooking oil filter machine:
Rapeseed oil, cotton seed oil, soybean oil, peanut oil, groundnut
oil, flax seed oil, sunflower seed oil, coconut oil, olive oil,
sesame oil, nut oil, grains oil, castor oil, mustard oil, palm oil,
copra oil
Quick Detail of cooking oil filter machine:
air pressure oil filter is a classical equipment which is mainly
for filtering different kinds of crude oil to separate solide and
impurity and is workable with any type of oil press.
Specifications of cooking oil filter machine:
| Model | RF600-S |
| Capacity | 80-100kg/h |
| Power | 2.2kw-2P |
| Weight | 170kg |
| Outline Dimension | 1000*650*1100mm |
| Voltage | 380V |
| Pressure | 0.03-0.07Mpa |
| Oil Temperature | 50-80℃ |
| Filtering Barrel Diameter | 580mm |
| Model | RF600-D |
| Capacity | 120-200kg/h |
| Power | 2.2kw-2P |
| Weight | 230kg |
| Outline Dimension | 1400*800*1100mm |
| Voltage | 380V |
| Pressure | 0.03-0.07Mpa |
| Oil Temperature | 50-80℃ |
| Filtering Barrel Diameter | 580mm |
Description of cooking oil filter machine:
The Air pressure filter is used to remove the oil on the surface of
the vacuum oil filter, and the oil is sucked into the vacuum drum
through the filter cloth, and the dross is isolated on the surface
of the filter cloth, and has the characteristics of high processing
speed and simple operation, and is suitable for the filtering of
the oil of the cooked oil.
The Air pressure filter removes free water and solid contaminants
with high efficiency. The oil filter removes free water from the
medium through demulsification, coalescence, and separation
processes. The free water content of the treated media is less than
200 PPM and can be less than 100 PPM at the limit. It also filters
solid particles in the media to control fluid cleanliness.
This machine works good for the oil mill users, filtering rapeseed
oil and peanut oil, sunflower oil, soybean oil and other oils, the
filtered oil won’t contain foam, less soot, no sediment, improve
oil yield. It has the characteristics of simple operation, reliable
performance and high filtration efficiency.
Competitive Advantage of cooking oil filter machine:
- Simple operation
- Reliable performance
- High filtration efficiency
- Wide range of oil material
- Persistence service.
- Fast filtering speed and convenient operation.
- Compared with other equipment, it does not need any consumables for
long-term use, and there is no filter cloth cleaning and filter
cloth consumption.
- saving electricity
- the use effect is better than all other filtering equipment, such
as the trouble of replacing the filter cloth and the filter cloth
with the oil of the frame frame oil machine, the danger of pressure
filtration overpressure and the defect of excessive opening of the
sludge, and the use of the centrifugal filter No consumables are
purchased, saving energy and time, good effect, high oil purity,
clear color, can be directly filled for sale or directly consumed
